Checks Land Rover sold worldwide since 2000, support 59 systems Including Engine, A/T, ABS, Airbag, ENG, Body Control module, Chassis control module, Packing brake control, Steering angle sensor module, Speed control module, etc
Available Functions:
l Reads and clears generic and manufacturer specific Diagnostic Trouble Codes (DTCs).
l Determines the malfunction indicator lamp(MIL) status
l Identifies and displays pending codes.
l Retrieves VIN(Vehicle Identification No.) on 2002 and newer vehicles that support Mode 9
l Wider vehicles coverage with CAN protocol support;
l Displays total # of codes retrieved
l Code definitions displayed on unit screen;
l Displays I/M readiness status;
2. Works with Land Rover sold worldwide since 2000, support 59 systems Including Engine, A/T, ABS, Airbag, ENG, Body Control module, Chassis control module, Packing brake control, Steering angle sensor module, Speed control module, etc
Available functions:
l Reads and clears generic trouble codes of cars using ISO 9141-2 (CARB), ISO 14230 (KWP-2000) and ISO-15765(CAN) protocols.
l Displays total # of codes retrieved;
l Code definitions displayed on unit screen;
l Turns off MIL lights of engine, airbags, ABS, A/T and most other systems
l Views the ECU information.
l Reset service for all brands of Land Rover
l oil reset EPB reset Brake bleeding SLS reset Battery reset.
l One Year warranty.
|
Language |
English, other language custornized |
|
Protocol |
OBDII, CAN, KWP |
|
Support |
Land Rover all systems |
|
External Power |
8.0 to 18.0 V power provided via vehicle battery |
|
Display |
TFT colorful display |
|
Working Temperature |
0 to 60°C (32 to 140 F°) |
|
Storage Temperature |
-20 to 70°C (-4 to 158 F°) |
|
Certificate |
CE ROHS FCC PAHS REACH |
|
Warranty |
One Year |
|
Size |
120(L)*72(W)*15 (H)mm |
|
Weight |
200g |
